Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Body Style | Cylindrical |
| Connection Type | QD Integral |
| Diameter, Body | 30 |
| Housing Material | Thermoplastic |
| Humidity | 90% @ 50 C |
| Indicator | LEDs |
| Input Output | Solid-State AC Switch |
| IP Rating | IP67 |
| Light Source | Infrared LED |
| Maximum Operating Temperature | 70 C |
| Measurement Range | 150 m |
| Mechanical Angle | 10 |
| Minimum Operating Temperature | -40 C |
| Mounting Type | M30 Threaded |
| NEMA Rating | NEMA 6P |
| Number of Pins | 3 |
| Operating Temperature, Maximum | 70 C |
| Operating Temperature, Minimum | -40 C |
| Output | SPST |
| Response Time | 10 ms |
| Sensing Mode | Through Beam Receiver |
| Sensing Range | 150000 |
| Series | |
| Supply Voltage | 24-240 VAC |
| Type | Through Beam Sensors |
