Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | 33384 |
| Body Style | Rectangular |
| Cable Length | 2 m |
| Connection Type | Cable |
| Diameter, Body | 30 |
| Housing Material | Thermoplastic |
| Humidity | 90% @ 50 C |
| Indicator | LEDs |
| Input Output | Solid-State AC Switch |
| IP Rating | IP67 |
| Light Source | Visible Red LED |
| Maximum Operating Temperature | 70 C |
| Measurement Range | 6 m |
| Mechanical Angle | 16 |
| Minimum Operating Temperature | -40 C |
| Mounting Type | M30 Threaded |
| NEMA Rating | NEMA 6P |
| Number of Pins | 3 |
| Operating Temperature, Maximum | 70 C |
| Operating Temperature, Minimum | -40 C |
| Output | SPST |
| Response Time | 16 ms |
| Sensing Mode | Retroreflective |
| Sensing Range | 6000 |
| Series | |
| Supply Voltage | 20-250 VAC |
| Time, Turn-On Delay | 100 ms |
| Type | Retroreflective Sensors |
